Parameter	Symbol	Conditions	Min	Typ	Max	Unit
Supply Voltage	VCC	-	4.5	-	20	V
Output Current	IO	Per output, Ta = 25掳C	-	150	-	mA
Power Dissipation	PD	Ta = 25掳C	-	-	650	mW
Operating Temp.	TOPR	-	-40	-	85	掳C
Storage Temp.	TSTG	-	-55	-	150	掳C

Instructions for TD62785P:

1. Supply Voltage: Ensure the supply voltage is within the range of 4.5V to 20V to avoid damage to the device.
2. Output Current: Each output can handle up to 150mA at room temperature (25掳C). For higher temperatures or multiple outputs, ensure the total current does not exceed safe limits.
3. Power Dissipation: The maximum power dissipation at room temperature is 650mW. Proper heat sinking may be required if operating near this limit.
4. Operating Temperature: The device is designed to operate between -40掳C and 85掳C. Ensure environmental conditions are within this range.
5. Storage Temperature: When not in use, store the device between -55掳C and 150掳C.
6. Handling Precautions: Handle with care to avoid electrostatic discharge (ESD) damage. Use appropriate ESD protection measures during handling and installation.
7. Mounting: Ensure proper mounting techniques to maintain thermal performance and mechanical integrity. Follow manufacturer guidelines for PCB layout and component placement.

(For reference only)
