Parameter	Symbol	Min	Typ	Max	Unit	Conditions
Collector-Emitter Voltage	VCE	-	-	50	V
Emitter-Base Voltage	VEB	-2.5	-	2.5	V
Collector Current	IC	-	-	1.5	A
Base Current	IB	-	-	0.15	A
Power Dissipation	PT	-	-	62.5	W	Ta = 25掳C
Storage Temperature Range	TSTG	-55	-	150	掳C
Operating Temperature Range	TA	-55	-	150	掳C

Instructions for Use:

1. Mounting:

   • Ensure that the transistor is mounted on a suitable heatsink to dissipate the heat effectively, especially when operating at high power levels.
   • Use thermal compound between the transistor and the heatsink to improve thermal conductivity.

2. Biasing:

   • The base-emitter voltage (V_BE) should be kept within the specified limits to avoid damage.
   • The collector current (I_C) should not exceed the maximum rating to prevent overheating and potential failure.

3. Power Dissipation:

   • The power dissipation (P_T) must be managed to ensure the device does not exceed its maximum temperature ratings.
   • Consider derating the power dissipation if operating in environments with higher ambient temperatures.

4. Storage and Handling:

   • Store the transistor in a dry, cool place away from direct sunlight and extreme temperatures.
   • Handle the transistor with care to avoid mechanical stress and static discharge.

5. Testing:

   • When testing the transistor, use appropriate test equipment and ensure that all voltages and currents are within the specified limits.
   • Avoid applying excessive voltage or current during testing to prevent damage.

6. Safety:

   • Always follow proper safety procedures when working with electrical components.
   • Ensure that the circuit is powered off and discharged before making any connections or modifications.

(For reference only)
