| Parameter | Description |
|---|---|
| Part Number | GAL20V8B-15QP |
| Type | Programmable Logic Device (PLD) |
| Manufacturer | Lattice Semiconductor |
| Package | 20-Pin Plastic Quad Flat Pack (PQFP) |
| Operating Voltage | 3.3V to 5V |
| Input Voltage Range | -0.5V to VCC + 0.5V |
| Output Voltage Range | -0.5V to VCC + 0.5V |
| Max Power Consumption | 600 mW at VCC = 5V, TA = 25掳C |
| Propagation Delay | 5 ns (typical) |
| Power Supply Current | 10 mA (max) |
| Operating Temperature Range | -40掳C to +85掳C |
| Storage Temperature Range | -65掳C to +150掳C |
| Humidity Level | 60% RH |
Instructions:
- Power Supply: Ensure the operating voltage is within the specified range of 3.3V to 5V.
- Installation: Carefully insert the GAL20V8B-15QP into a compatible socket or PCB ensuring correct orientation and pin alignment.
- Programming: Use appropriate programming software and hardware compatible with GAL devices for configuration. Verify all connections before applying power.
- Handling Precautions: Handle with care to avoid damage from electrostatic discharge (ESD). Store in anti-static packaging when not in use.
- Environmental Conditions: Operate within the specified temperature and humidity ranges to ensure reliable performance and longevity.
- Testing: After installation and programming, test the device under typical operating conditions to confirm functionality.
