Details

---

BUY HYC9088A-LF https://www.utsource.net/itm/p/12611838.html

Parameter	Description	Value
Part Number	HYC9088A-LF
Package Type	SOP-8
Operating Voltage	Supply voltage range	2.7V to 5.5V
Operating Current	Active current	1.5mA (Typical)
Standby Current	Standby current	0.1渭A (Typical)
Frequency Range	Operating frequency range	300kHz to 2.6MHz
Temperature Range	Operating temperature range	-40掳C to +85掳C
Output Type	Open drain output
Load Capacitance	External load capacitance for crystal oscillator	12pF
Power-down Mode	Low power consumption mode	Supported

Instructions for Use:

1. Power Supply:

   • Ensure the supply voltage is within the specified range of 2.7V to 5.5V to avoid damage to the device.

2. Installation:

   • Mount the component on a PCB with appropriate soldering techniques suitable for SOP-8 packages.

3. Oscillator Configuration:

   • Connect an external crystal or ceramic resonator with a load capacitance of 12pF for stable operation.

4. Power Management:

   • Utilize the power-down mode to reduce power consumption when not in use. This can be activated by setting the appropriate control pin low.

5. Operating Environment:

   • Operate within the temperature range of -40掳C to +85掳C to ensure reliable performance.

6. Signal Integrity:

   • Keep signal traces as short as possible and use proper grounding techniques to minimize noise and interference.

7. Handling Precautions:

   • Handle with care to avoid static damage. Use anti-static precautions during handling and installation.

(For reference only)
