Parameter	Symbol	Min	Typ	Max	Unit	Notes
Input Voltage	VIN	4.5	-	40	V
Output Voltage	VOUT	-	5.0	-	V	Fixed
Output Current	IOUT	-	1.0	1.5	A
Quiescent Current	IQ	-	30	50	渭A
Dropout Voltage	VDROPOUT	-	0.2	0.5	V	@ IOUT = 1.0A, VIN = 5.0V
Load Regulation	-	-	0.5	2.0	%	@ IOUT = 0 to 1.5A
Line Regulation	-	-	0.1	0.5	%/V	@ VIN = 4.5 to 40V, IOUT = 1.0A
Ripple Rejection	-	60	70	80	dB	@ 100Hz, IOUT = 1.0A
Operating Temperature	Toper	-40	-	125	掳C
Storage Temperature	Tstg	-65	-	150	掳C

Instructions for Use:

1. Input Voltage (VIN):

   • Ensure the input voltage is within the range of 4.5V to 40V.
   • Do not exceed the maximum input voltage to avoid damaging the device.

2. Output Voltage (VOUT):

   • The output voltage is fixed at 5.0V. No external components are required to set this voltage.

3. Output Current (IOUT):

   • The device can provide a continuous output current up to 1.5A, with a typical output current of 1.0A.
   • For higher current applications, ensure proper heat dissipation.

4. Quiescent Current (IQ):

   • The quiescent current is typically 30渭A and can go up to 50渭A.
   • This current is drawn by the device even when no load is connected.

5. Dropout Voltage (VDROPOUT):

   • The dropout voltage is the minimum difference between the input and output voltages required to maintain regulation.
   • At a typical output current of 1.0A and an input voltage of 5.0V, the dropout voltage is between 0.2V and 0.5V.

6. Load Regulation:

   • The load regulation is the change in output voltage due to changes in load current.
   • It is specified as 0.5% to 2.0% over the load range from 0 to 1.5A.

7. Line Regulation:

   • The line regulation is the change in output voltage due to changes in input voltage.
   • It is specified as 0.1% to 0.5% per volt of input voltage change.

8. Ripple Rejection:

   • The ripple rejection is the ability of the device to suppress input voltage ripple.
   • It is specified as 60dB to 80dB at 100Hz and an output current of 1.0A.

9. Operating Temperature (Toper):

   • The device is designed to operate within a temperature range of -40掳C to 125掳C.
   • Ensure the ambient temperature does not exceed these limits to prevent thermal shutdown or damage.

10. Storage Temperature (Tstg):

    • The device can be stored within a temperature range of -65掳C to 150掳C.
    • Avoid exposing the device to extreme temperatures for extended periods to maintain reliability.

Additional Notes:

• Always use appropriate decoupling capacitors on both the input and output to ensure stable operation.
• For high current applications, consider using a heatsink to improve thermal performance.
• Refer to the datasheet for detailed information and application circuits.

(For reference only)
