Parameter	Value	Unit
Capacitance	8 pF	pF
Voltage Rating	50 V	V
Tolerance	卤5%	%
Temperature Coefficient	NPO (0 卤30 ppm/掳C)	ppm/掳C
Operating Temperature	-55 to +125 掳C	掳C
Insulation Resistance	>1000 M惟 at 25掳C	M惟
Dissipation Factor	<0.1% at 1 MHz	%

Instructions for Use:

1. Handling:

   • Handle the CL08-08 with care to avoid mechanical damage.
   • Use appropriate ESD protection to prevent electrostatic discharge.

2. Mounting:

   • Ensure that the mounting surface is clean and free from contaminants.
   • Solder the component using a temperature-controlled soldering iron.
   • Avoid excessive heat and pressure during soldering to prevent damage.

3. Storage:

   • Store the CL08-08 in a dry, cool place to prevent moisture absorption.
   • Keep the components away from direct sunlight and sources of heat.

4. Testing:

   • Use a high-impedance capacitance meter for accurate measurements.
   • Ensure the circuit is powered off and capacitors are discharged before testing.

5. Soldering:

   • Preheat the PCB to 100-120掳C to reduce thermal shock.
   • Apply solder paste or flux to the pads.
   • Place the component on the pads and reflow solder at the recommended temperature profile.

6. Inspection:

   • Visually inspect the solder joints for proper wetting and absence of voids.
   • Use an X-ray inspection if necessary to ensure internal connections are intact.

7. Environmental Considerations:

   • The CL08-08 is designed to operate within specified temperature ranges.
   • Avoid exposing the component to extreme temperatures or corrosive environments.

8. Disposal:

   • Dispose of the component in accordance with local environmental regulations.
   • Recycle where possible.

(For reference only)
