Parameter	Symbol	Min	Typical	Max	Unit	Conditions
Collector-Emitter Voltage	V CES	-	-	60	V
Collector Current	I C	-	-	5.5	A	T C = 25掳C
Power Dissipation	P TOT	-	-	74	W	T C = 25掳C
Junction Temperature	T J	-	-	150	掳C
Storage Temperature	T STG	-55	-	150	掳C
Thermal Resistance, Junction to Case	R 胃JC	-	-	0.85	掳C/W

Instructions for BUK555-60A

1. Handling and Storage:

   • Store in a dry place within the specified storage temperature range (-55掳C to 150掳C).
   • Handle with care to avoid mechanical damage.

2. Mounting:

   • Ensure proper heat sinking to manage the junction temperature, especially when operating at high power levels.
   • Use appropriate mounting hardware and thermal compound to enhance thermal conductivity.

3. Electrical Connections:

   • Connect the collector, emitter, and base according to the circuit diagram.
   • Ensure all connections are secure and insulated as necessary to prevent short circuits.

4. Operational Limits:

   • Do not exceed the maximum ratings listed in the parameter table.
   • Operate within the specified temperature range to ensure reliable performance.

5. Testing:

   • Before full-scale operation, conduct initial testing under controlled conditions to verify correct installation and functionality.

6. Safety Precautions:

   • Always use protective equipment when handling electrical components.
   • Follow all safety guidelines provided by the manufacturer.

(For reference only)
