Parameter	Symbol	Conditions	Min	Typ	Max	Unit
Supply Voltage	VDD	Operating range	2.7		5.5	V
Input Voltage Range	VIN		0		VDD	V
Output Voltage Range	VOUT		0		VDD	V
Quiescent Current	IQ	VDD = 5V		10		渭A
Shutdown Current	ISD	VSD = VDD, VS = GND		0.1		渭A
Propagation Delay	tPD	VDD = 5V, VI = 0 to VDD		30		ns
Rise Time	tr	VDD = 5V		40		ns
Fall Time	tf	VDD = 5V		40		ns

Instructions for TC1413N

1. Power Supply Connection:

   • Connect the supply voltage (VDD) between 2.7V and 5.5V to the VDD pin.
   • Ensure a stable power supply to avoid erratic behavior.

2. Input Signal Handling:

   • Apply input signals within the range of 0V to VDD.
   • Avoid exceeding the maximum input voltage to prevent damage.

3. Output Signal Monitoring:

   • The output signal will be within the range of 0V to VDD.
   • Monitor the output for correct operation and signal integrity.

4. Quiescent Current Management:

   • The device typically draws around 10渭A at 5V supply.
   • Keep this in mind for power budget considerations.

5. Shutdown Mode Operation:

   • To enter shutdown mode, set the shutdown pin (VSD) to VDD and the enable pin (VS) to GND.
   • In shutdown mode, the current draw is approximately 0.1渭A.

6. Timing Considerations:

   • Ensure that timing requirements are met, especially propagation delay, rise time, and fall time.
   • These parameters are crucial for synchronous operations with other components.

7. Handling and Storage:

   • Store the component in an ESD-safe environment.
   • Handle with care to avoid static damage.

8. Mounting and Layout:

   • Follow recommended PCB layout guidelines for optimal performance.
   • Place decoupling capacitors close to the power pins for stability.

(For reference only)
