Details

---

BUY PQ1CY1032Z https://www.utsource.net/itm/p/12611946.html

Parameter	Value	Unit
Part Number	PQ1CY1032Z	-
Type	Capacitor	-
Capacitance	10 渭F	渭F
Voltage Rating	32 V	V
Tolerance	卤10%	%
Operating Temp.	-55掳C to +85掳C	掳C
Case Size	5.6 x 5.6 mm	mm
Termination Style	SMD	-
Compliance	RoHS Compliant	-

Instructions for Use:

1. Handling:

   • Handle with care to avoid mechanical damage.
   • Do not apply excessive force when mounting or soldering.

2. Mounting:

   • Ensure the PCB is clean and free from contaminants.
   • Place the capacitor on the PCB according to the polarity markings (if applicable).
   • Use a soldering iron with a temperature setting appropriate for SMD components (typically 300-350掳C).

3. Soldering:

   • Apply a small amount of solder paste to the pads.
   • Place the capacitor on the pads and reflow the solder using a reflow oven or hot air station.
   • Ensure the solder joints are smooth and free from bridges or voids.

4. Inspection:

   • Visually inspect the solder joints for quality.
   • Check for any physical damage or misalignment of the component.

5. Storage:

   • Store in a dry, cool place away from direct sunlight.
   • Use within the recommended storage period to ensure optimal performance.

6. Environmental Considerations:

   • Dispose of the component according to local environmental regulations.
   • Recycle where possible.

(For reference only)
