Parameter	Symbol	Min	Typ	Max	Unit	Description
Supply Voltage	VDD	2.7	-	5.5	V	Operating supply voltage
Standby Current	ISB	-	1	-	渭A	Supply current in standby mode
Active Current	IOP	-	10	-	mA	Supply current in active mode
Output Voltage	VOUT	-	3.3	-	V	Regulated output voltage
Load Regulation	-	-	0.5	-	%	Change in output voltage with load
Line Regulation	-	-	0.5	-	%	Change in output voltage with input voltage
Dropout Voltage	VDROPOUT	-	0.3	-	V	Minimum difference between VIN and VOUT
Operating Temperature	Toper	-40	-	85	掳C	Operating temperature range
Storage Temperature	Tstg	-65	-	150	掳C	Storage temperature range
Thermal Resistance	胃JA	-	120	-	掳C/W	Junction-to-ambient thermal resistance

Instructions for Use:

1. Power Supply Connection:

   • Connect the VDD pin to the power supply.
   • Ensure the supply voltage is within the specified range (2.7V to 5.5V).

2. Ground Connection:

   • Connect the GND pin to the system ground.

3. Output Connection:

   • Connect the VOUT pin to the load or circuit that requires regulated power.

4. Capacitors:

   • Place a 10渭F ceramic capacitor between VDD and GND as close as possible to the device to ensure stability.
   • Place a 10渭F ceramic capacitor between VOUT and GND to filter noise and stabilize the output.

5. Thermal Management:

   • Ensure adequate heat dissipation if operating at high currents or temperatures.
   • The device can operate up to 85掳C ambient temperature, but thermal resistance should be considered for higher loads.

6. Standby Mode:

   • To enter standby mode, set the enable pin (if available) to a low state.
   • Standby current is typically around 1渭A.

7. Operating Temperature:

   • The device is rated for operation from -40掳C to 85掳C.
   • For storage, the temperature range is -65掳C to 150掳C.

8. Handling Precautions:

   • Handle the device with care to avoid static damage.
   • Follow proper soldering techniques to prevent thermal shock and mechanical stress.
