Parameter	Symbol	Min	Typical	Max	Unit
Supply Voltage	Vcc	4.5	5.0	5.5	V
Operating Current	Iop	-	10	30	mA
Output Voltage	Vo	0.1	3.5	4.9	V
Input Voltage	Vi	0.1	4.5	5.0	V
Rise Time	Tr	-	10	20	ns
Fall Time	Tf	-	10	20	ns
Propagation Delay	Tpd	-	15	25	ns
Power Dissipation	Pd	-	150	250	mW

Instructions for Using THX203H

1. Power Supply:

   • Ensure the supply voltage (Vcc) is within the range of 4.5V to 5.5V.
   • Use a stable power source to avoid fluctuations that could affect performance.

2. Input Voltage:

   • The input voltage (Vi) should be between 0.1V and 5.0V to ensure proper operation.
   • Avoid exceeding the maximum input voltage to prevent damage to the component.

3. Output Voltage:

   • The output voltage (Vo) will typically range from 0.1V to 4.9V, depending on the input conditions.
   • Monitor the output to ensure it remains within the expected range for your application.

4. Operating Current:

   • The operating current (Iop) can vary between 10mA and 30mA.
   • Ensure your power supply can handle the maximum current requirement.

5. Timing Parameters:

   • The rise time (Tr) and fall time (Tf) are typically around 10ns but can extend up to 20ns.
   • The propagation delay (Tpd) is typically 15ns but can reach up to 25ns.
   • These parameters are crucial for timing-sensitive applications.

6. Power Dissipation:

   • The power dissipation (Pd) should not exceed 250mW to avoid overheating.
   • Ensure adequate cooling if the component is used in high-power applications.

7. Handling and Storage:

   • Handle the THX203H with care to avoid static damage.
   • Store in a dry, cool place away from direct sunlight and extreme temperatures.

8. Mounting:

   • Follow the recommended PCB layout and soldering guidelines to ensure reliable performance.
   • Use appropriate heat sinks if necessary to manage thermal dissipation.

By following these instructions, you can ensure optimal performance and longevity of the THX203H component.
