Parameter	Description	Value
Part Number		136S6D
Type	Surface Mount Resistor
Resistance	Nominal Resistance	6.0 惟
Tolerance	Resistance Tolerance	卤5%
Power Rating	Maximum Power Dissipation	0.125 W (1/8 W)
Operating Temp	Operating Temperature Range	-55掳C to +125掳C
Case Size	Standard Case Size	0603 (1608 Metric)
Material	Resistor Body Material	Ceramic
Termination	Termination Type	Solder
Compliance	RoHS Compliance	Yes
Packaging	Packaging Type	Tape & Reel

Instructions for Use:

1. Handling:

   • Handle with care to avoid mechanical damage.
   • Use appropriate ESD (Electrostatic Discharge) precautions.

2. Mounting:

   • Place the resistor on the PCB (Printed Circuit Board) as per the design layout.
   • Ensure the solder pads are clean and free from contaminants.
   • Apply a small amount of solder paste to the pads if using reflow soldering.

3. Soldering:

   • Use a soldering iron or reflow oven with a temperature profile suitable for surface mount components.
   • For hand soldering, use a temperature range of 300掳C to 350掳C.
   • For reflow soldering, follow the recommended temperature profile:
     • Preheat: 120掳C to 150掳C for 60 to 90 seconds.
     • Soak: 170掳C to 190掳C for 60 to 90 seconds.
     • Reflow: 210掳C to 230掳C for 30 to 60 seconds.
     • Cooling: Natural cooling to room temperature.

4. Inspection:

   • Visually inspect the solder joints for proper wetting and no voids.
   • Use a multimeter to verify the resistance value if necessary.

5. Storage:

   • Store in a dry, cool place away from direct sunlight.
   • Keep the components in their original packaging until ready for use.

6. Disposal:

   • Dispose of any defective or unused components according to local environmental regulations.

(For reference only)
