Parameter	Conditions	Min	Typ	Max	Unit
Supply Voltage (VCC)		1.65		5.5	V
Propagation Delay Time	VCC = 3.3V, TA = 25掳C		4.8		ns
Power Dissipation				100	mW
Operating Temperature		-40		85	掳C
Storage Temperature		-65		150	掳C

Instructions for SN74LVC1G74DCTR:

1. Power Supply:

   • Ensure the supply voltage (VCC) is within the range of 1.65V to 5.5V to avoid damage or incorrect operation.

2. Propagation Delay:

   • The typical propagation delay time is 4.8ns at a supply voltage of 3.3V and an ambient temperature of 25掳C. Adjustments may be needed for different conditions.

3. Thermal Considerations:

   • Keep the power dissipation below 100mW to ensure reliable operation and prevent overheating.
   • Operate the device within the temperature range of -40掳C to 85掳C for optimal performance. Store in environments between -65掳C and 150掳C.

4. Handling:

   • Handle with care to avoid electrostatic discharge (ESD) which can damage the component. Use proper ESD protection measures during handling and installation.

5. Applications:

   • This D-type flip-flop is suitable for applications requiring data storage and signal processing in digital circuits. Ensure correct connections for clock (CP), data (D), set (SD), reset (RD), and output (Q, Q-bar).

6. Installation:

   • Follow standard surface-mount technology (SMT) procedures for installation on PCBs. Verify all solder joints are secure and free from shorts or cold solder joints.
