Parameter	Description	Value
Part Number	Component Identifier	SDT-SS-105DM
Type	Component Type	Solid State Relay (SSR)
Input Voltage	Range of input voltage for control	3 to 32 VDC
Input Current	Typical current required for operation	5 mA (max 10 mA)
Output Voltage	Maximum output voltage rating	60 VAC/DC
Output Current	Maximum continuous output current	5 A
Isolation Voltage	Voltage isolation between input and output	4000 VAC (1 min)
Switching Time	Time taken to switch on/off	1 ms (max)
Operating Temperature	Range of ambient temperature for operation	-40掳C to +85掳C
Storage Temperature	Range of ambient temperature for storage	-55掳C to +125掳C
Mounting Type	Method of mounting	Surface Mount (SMD)
Package/Case	Physical dimensions and shape	DIP-4
Lead Pitch	Distance between leads	2.54 mm
Weight	Weight of the component	0.5 g

Instructions:

1. Power Supply: Ensure the input voltage is within the specified range (3 to 32 VDC) to avoid damage.
2. Load Connection: Connect the load to the output terminals, ensuring the load current does not exceed 5 A.
3. Heat Dissipation: For high current applications, ensure adequate heat dissipation to maintain operating temperatures within the specified range.
4. Isolation: The relay provides 4000 VAC isolation between input and output. Do not exceed this voltage to prevent electrical breakdown.
5. Mounting: Use surface mount techniques suitable for DIP-4 packages. Ensure proper soldering to avoid mechanical stress.
6. Environmental Conditions: Store and operate the relay within the specified temperature ranges to ensure reliable performance.
7. Testing: Before final assembly, test the relay under normal operating conditions to verify functionality.
