BUY 9N150 https://www.utsource.net/itm/p/12612055.html

Parameter	Symbol	Min	Typical	Max	Unit
Forward Voltage	VF	-	1.2	1.6	V
Reverse Breakdown Voltage	VBR	-	100	-	V
Forward Current	IF	-	50	100	mA
Reverse Current	IR	-	100	500	nA
Power Dissipation	PT	-	100	-	mW
Operating Temperature	Top	-40	-	125	掳C
Storage Temperature	Tstg	-65	-	150	掳C

Instructions for Use:

1. Forward Voltage (V_F):

   • The typical forward voltage is 1.2V, but it can range from 1.2V to 1.6V.
   • Ensure the supply voltage is within this range to avoid damage.

2. Reverse Breakdown Voltage (V_BR):

   • The device can withstand up to 100V in reverse bias.
   • Exceeding this voltage can cause permanent damage.

3. Forward Current (I_F):

   • The typical forward current is 50mA, with a maximum of 100mA.
   • Exceeding the maximum current can lead to overheating and failure.

4. Reverse Current (I_R):

   • The typical reverse leakage current is 100nA, with a maximum of 500nA.
   • High reverse currents indicate potential issues and should be investigated.

5. Power Dissipation (P_T):

   • The maximum power dissipation is 100mW.
   • Ensure proper heat sinking if operating near this limit to prevent thermal runaway.

6. Operating Temperature (T_op):

   • The device can operate between -40掳C and 125掳C.
   • Avoid operating in extreme temperatures to maintain reliability.

7. Storage Temperature (T_stg):

   • Store the device between -65掳C and 150掳C.
   • Proper storage conditions ensure long-term reliability.

8. Handling Precautions:

   • Handle the device with care to avoid mechanical stress.
   • Use appropriate ESD protection to prevent damage from static electricity.

9. Mounting:

   • Follow recommended soldering profiles to ensure reliable connections.
   • Avoid excessive heat during soldering to prevent damage to the device.

10. Testing:

    • Use a multimeter or other appropriate test equipment to verify the device parameters before use.
    • Regular testing can help identify potential issues early.

(For reference only)
