Parameter	Value	Unit
Supply Voltage (Vcc)	5.5 to 28	V
Continuous Current (Iout)	卤42	A
Peak Current (Iout)	卤60	A
Power Dissipation	110	W
Operating Temperature	-40 to +125	掳C
Package Type	QFN-32
Protection Features	Overcurrent, short-circuit,
	thermal shutdown

Instructions for BTN7971BAUMA1

1. Power Supply Connection:

   • Connect the supply voltage (Vcc) within the range of 5.5V to 28V.
   • Ensure a stable power supply to prevent damage from voltage spikes.

2. Current Handling:

   • Operate within the continuous current limit of 卤42A.
   • For peak currents up to 卤60A, ensure these conditions are not sustained for prolonged periods to avoid overheating.

3. Heat Management:

   • The device can dissipate up to 110W of power. Use appropriate heatsinking or cooling methods if operating near this limit.
   • Monitor the temperature and keep it within the operational range of -40掳C to +125掳C.

4. Protection Features:

   • The device includes built-in protection against overcurrent, short-circuit, and thermal overload. These features will automatically shut down the device under fault conditions to protect it from damage.

5. Installation:

   • Install using the QFN-32 package guidelines. Ensure proper soldering and mounting techniques to maintain electrical performance and reliability.

6. Testing:

   • After installation, test the device under controlled conditions to verify its operation and confirm that all connections are secure and functioning correctly.

(For reference only)
