Details

---

BUY FS70SM-06 https://www.utsource.net/itm/p/12612163.html

Parameter	Description
Part Number	FS70SM-06
Type	Surface Mount Fuse
Rating (A)	6 A
Voltage (V)	32 V
Breaking Capacity	50 A at 32 V DC
Dimensions	7.0 x 3.6 mm
Operating Temperature	-55掳C to +125掳C
Package Type	SMD (Surface Mount Device)
Compliance	RoHS, REACH, Halogen-Free

Instructions:

1. Installation: Ensure the fuse is installed in the correct orientation as indicated by the component marking.
2. Handling: Handle with care to avoid damage to the soldering pads and the fuse body.
3. Mounting: Use appropriate soldering techniques suitable for surface mount components. Preheat if necessary to prevent thermal shock.
4. Inspection: After installation, inspect the fuse and surrounding area for any solder shorts or misalignment.
5. Testing: Perform electrical tests as per your application requirements to ensure proper functionality.
6. Replacement: Replace only with a fuse of the same type and rating. Do not exceed the specified voltage and current ratings.

(For reference only)
