Parameter	Description	Value
Part Number	Component Identifier	D70108L-10
Type	Component Type	Diode
Package	Package Type	SOD-323
Polarity	Polarity	Unidirectional
Forward Voltage	Voltage Drop (Vf) at IF = 100 mA	1.0 V
Reverse Voltage	Maximum Reverse Voltage (Vr)	100 V
Forward Current	Maximum Forward Current (If)	150 mA
Peak Reverse Current	Peak Reverse Current (Irm)	5 A
Power Dissipation	Maximum Power Dissipation (Ptot)	200 mW
Operating Temperature	Operating Temp Range (Tamb)	-65掳C to +150掳C
Storage Temperature	Storage Temp Range (Tstg)	-65掳C to +150掳C
Capacitance	Capacitance (Cj) at Vr = 0 V, f = 1 MHz	4 pF
Reverse Recovery Time	Reverse Recovery Time (trr)	10 ns

Instructions for Use:

1. Mounting:

   • Ensure the diode is mounted with proper orientation to avoid reverse polarity.
   • Use a soldering iron with a temperature setting appropriate for the SOD-323 package, typically around 350掳C.

2. Handling:

   • Handle the diode by the body, not the leads, to prevent damage.
   • Avoid exposing the diode to excessive static electricity.

3. Soldering:

   • Apply solder quickly to minimize thermal stress on the diode.
   • Allow the diode to cool naturally after soldering.

4. Testing:

   • Use a multimeter to check for continuity and ensure the diode is functioning correctly.
   • Measure the forward voltage drop to verify it is within the specified range.

5. Storage:

   • Store the diode in a dry, cool place away from direct sunlight.
   • Keep the diode in its original packaging until ready for use to protect against static damage.

6. Application:

   • The D70108L-10 is suitable for general-purpose rectification and protection circuits.
   • Ensure the circuit design does not exceed the maximum ratings for forward current, reverse voltage, and power dissipation.

(For reference only)
