Parameter	Symbol	Min	Typ	Max	Unit
Collector-Emitter Voltage	VCE	-	-	700	V
Emitter-Base Voltage	VEB	-5	-	5	V
Collector Current	IC	-	-	15	A
Power Dissipation	PT	-	-	180	W
Junction Temperature	TJ	-55	-	150	掳C
Storage Temperature	TSTG	-65	-	150	掳C
Thermal Resistance, Junction to Case	R胃JC	-	0.65	-	掳C/W

Instructions for Using MJW21196

1. Mounting and Handling:

   • Ensure that the transistor is mounted on a heatsink to dissipate heat effectively.
   • Use proper anti-static precautions to avoid damaging the device.

2. Biasing:

   • The base-emitter voltage (V_BE) should be kept within the specified limits to avoid damage.
   • Ensure that the base current (I_B) is sufficient to fully saturate the transistor when used as a switch.

3. Power Dissipation:

   • Calculate the power dissipation (P_D) using the formula: P_D = V_CE * I_C.
   • Ensure that the power dissipation does not exceed the maximum rated value (180 W).

4. Temperature Considerations:

   • Monitor the junction temperature (T_J) to ensure it stays within the operational range (-55掳C to 150掳C).
   • Use thermal paste between the transistor and the heatsink to improve thermal conductivity.

5. Storage:

   • Store the transistor in a dry, cool place with temperatures ranging from -65掳C to 150掳C.

6. Testing:

   • Before installing the transistor in a circuit, test its parameters using a multimeter or a transistor tester to ensure it meets the specifications.

7. Circuit Design:

   • When designing circuits, consider the maximum ratings and ensure that the operating conditions do not exceed these limits.
   • Use appropriate protection circuits to prevent overvoltage and overcurrent conditions.

8. Safety:

   • Always follow safety guidelines when handling high-power devices.
   • Use insulated tools and wear protective gear when working with live circuits.

(For reference only)
