Parameter	Description	Value
Part Number	Component Identifier	CQ1565RT
Type	Device Type	Diode
Forward Voltage	Voltage drop across diode when conducting forward	0.7V
Reverse Current	Leakage current when diode is reverse biased	1nA at 25掳C
Peak Inverse Voltage	Maximum voltage diode can withstand in reverse bias	50V
Operating Temperature	Range of temperatures for operation	-40掳C to 85掳C
Storage Temperature	Temperature range for storage	-55掳C to 150掳C
Package	Type of packaging	SOT-23

Instructions for Use:

1. Mounting: Ensure the CQ1565RT is mounted on a PCB with adequate clearance from other components to prevent short circuits.
2. Soldering: Use a temperature-controlled soldering iron set no higher than 300掳C to avoid damaging the component.
3. Handling: Handle with care to avoid mechanical damage. Static electricity can also damage the device; use appropriate ESD precautions.
4. Testing: Before final assembly, test the diode using a multimeter to ensure it meets the specified forward and reverse characteristics.
5. Storage: Store in a dry, cool place within the specified storage temperature range to maintain performance characteristics.
6. Application: Suitable for general-purpose rectification and protection circuits where low forward voltage drop and low reverse current are required.

(For reference only)
