Details

---

BUY HDH-1003 https://www.utsource.net/itm/p/12612294.html

Parameter	Value	Description
Model Number	HDH-1003	High-Density Heat Sink
Material	Aluminum Alloy	Lightweight and high thermal conductivity
Dimensions	100mm x 100mm x 30mm	Width x Length x Height
Weight	500g	Approximate weight
Fin Design	Straight Fins	Optimized for air cooling
Fin Pitch	2.5mm	Distance between fins
**Base Thickness	5mm	Ensures good heat dissipation
**Mounting Holes	M4	Compatible with standard screws
Thermal Resistance	0.25掳C/W	Thermal performance indicator
Operating Temperature	-40掳C to 120掳C	Suitable for a wide range of environments
Surface Finish	Anodized Black	Corrosion resistance and improved aesthetics

Instructions for Use

1. Preparation:

   • Ensure the surface of the component to be cooled is clean and free of debris.
   • Apply a thin, even layer of thermal paste to the base of the heat sink.

2. Installation:

   • Align the heat sink with the mounting holes on the component.
   • Secure the heat sink using M4 screws, ensuring it is firmly attached but not over-tightened to avoid damage.

3. Operation:

   • Ensure adequate airflow around the heat sink for optimal cooling performance.
   • Monitor the temperature of the component regularly to ensure it remains within safe operating limits.

4. Maintenance:

   • Periodically clean the fins of the heat sink to remove dust and debris that can accumulate and reduce efficiency.
   • Reapply thermal paste if necessary, typically every 1-2 years or as needed.

5. Storage:

   • Store the heat sink in a dry, cool place when not in use to prevent corrosion and damage.

(For reference only)
