| Parameter | Value |
|---|---|
| Part Number | JQX-15F-012-1H6 |
| Type | Relay |
| Coil Voltage | 12V DC |
| Coil Resistance | 750惟 卤 10% |
| Contact Form | SPDT (Single Pole Double Throw) |
| Contact Rating | 10A, 250V AC / 30A, 30V DC |
| Insulation Resistance | >100M惟 at 500V DC |
| Dielectric Strength | 1500V AC for 1 minute |
| Operating Temperature | -40掳C to +85掳C |
| Storage Temperature | -40掳C to +85掳C |
| Operating Humidity | 95% RH at +40掳C |
| Contact Material | Silver Alloy |
| Terminal Connection | Solder Lug |
| Dimensions | 17.5mm x 12.5mm x 26.5mm |
| Weight | 12g |
Instructions:
- Installation: Ensure the relay is mounted on a flat surface with adequate ventilation to dissipate heat.
- Coil Connection: Connect the coil terminals to the appropriate power supply matching the rated coil voltage.
- Contact Wiring: Wire the load and control circuits to the common (COM), normally open (NO), and normally closed (NC) terminals as required by your application.
- Handling Precautions: Avoid exposing the relay to environments exceeding the specified operating and storage temperatures and humidity levels.
- Inspection: Regularly inspect the relay for signs of wear or damage, especially the contacts and insulation.
- Maintenance: Keep the relay clean and free from dust and contaminants that could affect performance.
- Disposal: Dispose of the relay according to local regulations concerning electronic waste.
