Parameter	Description	Value
Part Number	Product code	LE33CZ-TR
Type	Voltage Regulator	Linear
Output Voltage	Fixed output voltage	3.3V
Input Voltage	Operating input voltage range	4.5V to 20V
Output Current	Continuous output current	1A
Quiescent Current	Current consumption in operation	5mA
Dropout Voltage	Minimum difference between input and output	1.2V at 1A
Package	Component packaging type	TO-252 (DPAK)
Operating Temp	Temperature range for operation	-40掳C to +125掳C
Features	Special features	Short-circuit protection, thermal shutdown

Instructions:

1. Mounting: Ensure the LE33CZ-TR is mounted on a heatsink if operating near maximum output current to maintain optimal temperature.
2. Input Capacitor: Place a 0.1 渭F ceramic capacitor close to the input pin to stabilize the input voltage.
3. Output Capacitor: Use a 1 渭F tantalum or ceramic capacitor at the output for stability.
4. Power Supply: Ensure the input voltage does not exceed the maximum rated input voltage to prevent damage.
5. Heat Management: Monitor the junction temperature to avoid exceeding the maximum operating temperature.
6. Connections: Verify all connections are secure and correct before applying power to avoid potential damage to the regulator or connected circuits.
