Parameter	Symbol	Min	Typ	Max	Unit	Description
Input Voltage	VIN	6	-	30	V	Operating input voltage range
Output Voltage	VOUT	5	-	5	V	Regulated output voltage
Output Current	IOUT	-	1	1.5	A	Continuous output current
Quiescent Current	IQ	-	5	10	mA	Current consumption at no load
Dropout Voltage	VD	-	1.2	1.8	V	Voltage difference between VIN and VOUT for regulation
Thermal Shutdown	TSD	-	-	150	掳C	Temperature at which the device shuts down
Short-Circuit Protection	SCP	-	-	-	-	Automatically recovers when fault is removed
Operating Temperature	TOPR	-40	-	125	掳C	Range of ambient operating temperatures

Instructions for Use:

1. Input Connection:

   • Connect the positive terminal of the power supply to the input (VIN) pin.
   • Connect the negative terminal of the power supply to the ground (GND) pin.

2. Output Connection:

   • Connect the load to the output (VOUT) pin.
   • Ensure the ground (GND) pin is connected to the common ground of the load.

3. Capacitors:

   • Place a 10 渭F tantalum or ceramic capacitor between VIN and GND close to the regulator to stabilize the input voltage.
   • Place a 10 渭F tantalum or ceramic capacitor between VOUT and GND close to the regulator to stabilize the output voltage.

4. Thermal Considerations:

   • Ensure adequate heat dissipation if the regulator is expected to operate near its maximum output current.
   • Use a heatsink if the power dissipation exceeds the capabilities of the package.

5. Short-Circuit Protection:

   • The regulator has built-in short-circuit protection, but it is recommended to use external fuses or circuit breakers for additional safety.

6. Thermal Shutdown:

   • The device will shut down if the junction temperature exceeds 150掳C to prevent damage. It will automatically resume operation once the temperature returns to a safe level.

7. Storage and Handling:

   • Store the device in a dry, cool place.
   • Handle with care to avoid static discharge, which can damage the device.

8. Mounting:

   • Mount the regulator on a PCB with appropriate clearance to ensure proper heat dissipation and mechanical stability.

(For reference only)
