Parameter	Symbol	Min	Typ	Max	Unit
Rated Voltage	V_R	-	600	-	V
Rated Current	I_R	-	10	-	A
Reverse Recovery Time	t_rr	-	35	-	ns
Forward Voltage Drop	V_F	-	1.2	-	V @ 10A
Junction Temperature	T_j	-40	-	150	掳C
Storage Temperature	T_stg	-55	-	150	掳C

Instructions for Use:

1. Mounting:

   • Ensure the diode is mounted on a heatsink if operating near maximum current to maintain junction temperature within specified limits.
   • Use appropriate thermal paste to enhance heat dissipation.

2. Wiring:

   • Connect the anode (A) and cathode (K) terminals correctly to avoid reverse polarity damage.
   • Use wires with sufficient gauge to handle the rated current.

3. Operating Conditions:

   • Do not exceed the maximum rated voltage or current to prevent damage.
   • Ensure the ambient temperature does not exceed the storage temperature range.

4. Testing:

   • Test the diode using a multimeter to check for continuity and proper operation before installation.
   • Perform regular maintenance checks to ensure reliable performance.

5. Storage:

   • Store the diode in a dry, cool place away from direct sunlight and extreme temperatures.
   • Handle with care to avoid physical damage.

6. Safety:

   • Always disconnect power before handling the diode to avoid electrical shock.
   • Follow all relevant safety guidelines and regulations when working with high-voltage circuits.

(For reference only)
