Parameter	Symbol	Min	Typ	Max	Unit	Description
Drain-Source On-Resistance	RDS(on)	-	8.5	13	m惟	At VGS = 10V, ID = 9A
Gate-Threshold Voltage	VGS(th)	1.2	-	2.4	V	Gate-source voltage for ID = 250渭A
Continuous Drain Current	ID	-	-	9	A	TC = 25掳C
Pulse Drain Current	ID(pulse)	-	-	36	A	t = 10ms, TC = 25掳C
Power Dissipation	PD	-	-	2.4	W	TC = 25掳C
Total Capacitance	Ciss	-	270	-	pF	At VDS = 20V
Input Capacitance	Cin	-	240	-	pF	At VDS = 0V, f = 1MHz
Output Capacitance	Cout	-	20	-	pF	At VDS = 20V, f = 1MHz
Reverse Transfer Capacitance	Crss	-	50	-	pF	At VDS = 20V, f = 1MHz
