Parameter	Description	Value
Part Number	H30SR5
Type	Schottky Barrier Diode
Package	SOD-123
Forward Voltage (Vf)	@ 1A, 25掳C	0.5V
Reverse Voltage (Vr)	Maximum Reverse Voltage	50V
Average Rectified Current (Io)	@ 25掳C	3.0A
Peak Forward Surge Current (Ifsm)	8.2ms single half sine wave	30A
Total Power Dissipation (Ptot)	@ Ta = 25掳C	2W
Operating Temperature Range (Tj)	Junction Temperature	-65掳C to +175掳C
Storage Temperature Range (Tstg)	Storage Temperature	-65掳C to +175掳C
Thermal Resistance (Rth(j-a))	Junction to Ambient	125掳C/W
Capacitance (Cj)	@ 0V, 1MHz	40pF
Reverse Recovery Time (trr)	@ IF = 1A, dI/dt = 100A/渭s	35ns

Instructions for Use

1. Mounting and Handling:

   • Handle the diode with care to avoid damage to the leads and body.
   • Ensure that the mounting surface is clean and free of contaminants.
   • Use appropriate heat sinks if operating at high current or power levels.

2. Soldering:

   • Preheat the diode to 100掳C to 150掳C before soldering.
   • Soldering temperature should not exceed 260掳C.
   • Soldering time should be kept to a minimum, typically less than 5 seconds.

3. Electrical Connections:

   • Connect the diode in the correct polarity. The cathode (positive) lead is usually marked with a band or dot.
   • Ensure that the reverse voltage applied does not exceed the maximum rated reverse voltage (50V).

4. Thermal Management:

   • If the diode will be operating near its maximum power dissipation, ensure adequate cooling.
   • Use thermal paste or thermal interface materials to improve heat transfer from the diode to the heat sink.

5. Storage:

   • Store the diode in a dry, cool place away from direct sunlight.
   • Avoid exposure to high humidity and extreme temperatures.

6. Testing:

   • Before installing the diode, test it using a multimeter to ensure it is functioning correctly.
   • Check for continuity between the anode and cathode to verify that the diode is not shorted or open.

7. Environmental Considerations:

   • The diode is RoHS compliant and suitable for use in environmentally conscious designs.
   • Dispose of the diode according to local regulations for electronic waste.

By following these instructions, you can ensure optimal performance and longevity of the H30SR5 Schottky Barrier Diode.
