Below is the parameter table and instructions for the SKIIP38AC126V20.

Parameter Table

Parameter	Symbol	Min	Typ	Max	Unit	Conditions
Rated Voltage (DC)	VDC	-	1200	-	V
Rated Current (Continuous)	IC	-	126	-	A	Case temperature: 25°C
Peak Current (Pulse)	ICM	-	450	-	A	Pulse width ≤ 10 μs, duty cycle ≤ 1%
Thermal Resistance (Junction to Case)	Rth(j-c)	-	0.2	-	°C/W
Forward Voltage Drop	VF	-	1.8	-	V	IC = 126 A, Tj = 25°C
Reverse Recovery Time	trr	-	90	-	ns	IRM = 450 A, Tj = 25°C
Storage Temperature Range	Tstg	-40	-	150	°C
Operating Temperature Range	Top	-40	-	125	°C

Instructions

1. Handling and Storage:

   • Store the device in a dry, cool place away from direct sunlight and sources of heat.
   • Handle with care to avoid mechanical stress or damage to the leads and package.

2. Mounting:

   • Ensure that the mounting surface is clean and flat to ensure good thermal contact.
   • Use appropriate thermal interface materials (TIM) to enhance heat dissipation.
   • Tighten the screws to the recommended torque values to avoid over-tightening or under-tightening.

3. Electrical Connections:

   • Ensure that all connections are secure and free from oxidation or contamination.
   • Use wire gauges and connectors that can handle the rated current to prevent overheating.

4. Thermal Management:

   • The device should be mounted on a heatsink with sufficient thermal capacity to maintain the junction temperature within safe limits.
   • Monitor the case temperature during operation to ensure it does not exceed the maximum operating temperature.

5. Surge Protection:

   • Consider using external surge protection devices to protect the device from voltage spikes and transient currents.

6. Testing:

   • Perform initial testing at low power levels to verify proper operation before applying full load.
   • Regularly inspect the device and connections for signs of wear or damage.

7. Safety Precautions:

   • Always follow proper safety procedures when handling high-voltage and high-current circuits.
   • Use appropriate personal protective equipment (PPE) such as gloves and safety glasses.

By following these instructions, you can ensure the reliable and efficient operation of the SKIIP38AC126V20.
