Details

---

BUY JQX-105F-4-012D-1HS https://www.utsource.net/itm/p/12613843.html

Parameter	Value
Type	Relay
Model	JQX-105F-4-012D-1HS
Brand	JQX
Coil Voltage	12V DC
Coil Power	0.6W
Contact Form	4PDT (4 Form C)
Rated Load	10A/250V AC
Contact Resistance	≤50mΩ
Insulation Resistance	≥100MΩ at 500V DC
Dielectric Strength	2500V AC for 1 minute
Operating Temperature	-40°C to +85°C
Storage Temperature	-40°C to +125°C
Mechanical Life	10 million operations
Electrical Life	100,000 operations (resistive load)
Weight	35g

Instructions:

1. Installation:

   • Ensure the relay is mounted on a flat, stable surface.
   • Use the provided mounting holes for secure attachment.

2. Wiring:

   • Connect the coil terminals to the appropriate power source (12V DC).
   • Connect the common (COM), normally open (NO), and normally closed (NC) contacts to the circuit as required.

3. Operation:

   • When the coil is energized, the contacts will switch from their default state to the activated state.
   • The relay can handle up to 10A at 250V AC, but ensure the load does not exceed these ratings to avoid damage.

4. Testing:

   • Test the relay with a multimeter to verify the continuity of the contacts before connecting it to the main circuit.
   • Check the insulation resistance and dielectric strength to ensure proper functionality.

5. Maintenance:

   • Regularly inspect the relay for signs of wear or damage.
   • Clean the contacts if necessary using a soft, dry cloth.

6. Safety:

   • Always disconnect the power supply before performing any maintenance or testing.
   • Do not exceed the rated load or operating temperature range to prevent safety hazards.

7. Storage:

   • Store the relay in a dry, cool place away from direct sunlight and corrosive substances.

(For reference only)
