Parameter	Symbol	Min	Typical	Max	Unit	Notes
Rated Voltage	VBR(RMS)	-	1200	-	V
Rated Current (DC)	IF(AV)	-	10	-	A
Forward Voltage Drop	VF	-	1.8	2.2	V @ 10A
Reverse Leakage Current	IR	-	50	100	渭A @ 1200V, 25掳C
Junction Temperature	TJ	-40	-	150	掳C
Storage Temperature	TSTG	-65	-	150	掳C
Thermal Resistance	R胃JC	-	1.0	-	掳C/W

Instructions:

1. Mounting and Handling:

   • Use appropriate handling techniques to avoid damage to the device.
   • Ensure that the device is mounted on a heatsink if operating at high currents to maintain junction temperature within specified limits.

2. Electrical Connections:

   • Ensure that all electrical connections are secure and properly insulated.
   • Avoid exceeding the rated voltage and current to prevent damage or failure.

3. Thermal Management:

   • The thermal resistance (R_胃JC) should be considered when designing the cooling system to ensure the junction temperature remains below 150掳C.
   • Use thermal paste or a thermal pad between the device and the heatsink for better heat dissipation.

4. Storage and Operation:

   • Store the device in a dry, cool environment within the specified storage temperature range.
   • Operate the device within the specified junction temperature range to ensure reliable performance.

5. Testing and Inspection:

   • Regularly inspect the device for signs of wear or damage.
   • Test the device under controlled conditions to ensure it meets the specified parameters.

6. Safety Precautions:

   • Always follow safety guidelines when working with high voltages and currents.
   • Use protective equipment such as gloves and safety glasses when handling the device.

(For reference only)
