Parameter	Value	Unit
Device Type	IGBT Module	-
Package	SKIIP2+	-
Maximum Collector-Emitter Voltage (Vces)	1250	V
Maximum Collector Current (Ic)	800	A
Maximum Emitter Current (Ices)	40	A
Junction Temperature (Tj)	-40 to +150	掳C
Storage Temperature (Tstg)	-55 to +125	掳C
Operating Temperature (Topr)	-40 to +100	掳C
Thermal Resistance, Junction to Case (Rth,j-c)	0.17	K/W

Instructions for Use:

1. Installation:

   • Ensure that the installation environment is clean and free from conductive particles.
   • Securely mount the module on a heat sink with adequate thermal paste to ensure proper heat dissipation.

2. Electrical Connections:

   • Connect the collector terminal to the high-side circuitry.
   • Connect the emitter terminal to the low-side circuitry.
   • Ensure all connections are tight and secure to prevent arcing or loose connections.

3. Operating Conditions:

   • Operate within the specified voltage and current limits to avoid damage to the module.
   • Monitor the junction temperature to stay within the operational range to ensure longevity.

4. Safety Precautions:

   • Handle with care to avoid physical damage to the module.
   • Follow all safety guidelines when working with high voltages and currents.

5. Storage:

   • Store in a dry, cool place away from direct sunlight.
   • Keep in original packaging until ready for use to protect against static discharge.

6. Testing:

   • Perform initial testing under controlled conditions to validate performance parameters.
   • Regularly inspect for signs of wear or damage during operation.

(For reference only)
