Parameter	Description	Value	Unit
Part Number	Device Part Number	SKKT92B14E	-
Type	Device Type	IGBT Module	-
Configuration	Configuration	1 in 1	-
VCES	Collector-Emitter Voltage	1700	V
IC	Collector Current	900	A
Rth,jc	Thermal Resistance Junction to Case	0.25	K/W
Tj	Operating Junction Temperature Range	-40 to 150	掳C
Package	Package Type	PressFIT DUAL-PAK	-
Weight	Weight	86	g

Instructions for SKKT92B14E

1. Handling Precautions:

   • Use proper anti-static precautions when handling the module.
   • Avoid mechanical stress on the leads and terminals.

2. Mounting Instructions:

   • Ensure that the mounting surfaces are clean and flat.
   • Torque the mounting screws to the recommended specifications to avoid damage to the module.

3. Soldering Guidelines:

   • Preheat the module before soldering to minimize thermal shock.
   • Use a temperature-controlled soldering station set to no more than 260掳C.
   • Complete soldering within 10 seconds.

4. Electrical Connections:

   • Verify all connections are secure and properly insulated.
   • Ensure correct polarity when connecting the power supply.

5. Thermal Management:

   • Install a suitable heatsink to maintain the junction temperature within the specified range.
   • Monitor the temperature during operation to prevent overheating.

6. Storage Conditions:

   • Store in a dry, cool place away from direct sunlight.
   • Keep in original packaging until ready for use to protect against ESD.

7. Testing:

   • Perform initial testing under controlled conditions with appropriate safety measures.
   • Refer to the datasheet for detailed test procedures and expected performance metrics.

(For reference only)
