Details

---

BUY SLIMDIP-S https://www.utsource.net/itm/p/12613927.html

Parameter	Description
Package Type	SLIMDIP-S
Number of Pins	8
Pitch (mm)	1.27
Width (mm)	5.30
Length (mm)	9.60
Height (mm)	1.40 (max)
Lead Finish	Matte Tin
Operating Temperature	-40掳C to +85掳C
Storage Temperature	-65掳C to +150掳C
Moisture Sensitivity	Level 1 (unlimited floor life)
RoHS Compliance	Yes

Instructions for Handling and Assembly

1. Handling:

   • Use ESD (Electrostatic Discharge) protection equipment such as wrist straps and grounded workstations.
   • Handle the SLIMDIP-S by the edges to avoid touching the leads or the body.
   • Store in a dry, cool place to prevent moisture absorption.

2. Soldering:

   • Preheat the PCB to 100掳C to 120掳C to reduce thermal shock.
   • Use a soldering iron with a temperature range of 300掳C to 320掳C.
   • Apply a small amount of flux to the pads before soldering.
   • Solder each lead individually, ensuring that the solder wets both the pad and the lead.
   • Avoid applying excessive heat or pressure to the component.

3. Inspection:

   • Visually inspect the solder joints for proper wetting, alignment, and absence of shorts or bridges.
   • Use an X-ray inspection for internal connections if necessary.

4. Cleaning:

   • If cleaning is required, use a mild, non-corrosive cleaning solution and ensure the PCB is thoroughly dried afterward.

5. Testing:

   • Perform functional testing after assembly to ensure the component is operating correctly.
   • Check for any physical damage or misalignment that may affect performance.

6. Storage:

   • Store the assembled PCBs in a dry, static-protected environment.
   • Label the storage container with the date of assembly and any relevant handling instructions.

By following these guidelines, you can ensure the proper handling and assembly of the SLIMDIP-S package, minimizing the risk of damage and ensuring optimal performance.

(For reference only)
