Parameter	Value	Unit
Part Number	G9117-50T43U	-
Type	N-Channel MOSFET	-
Maximum Drain Voltage	500	V
Maximum Gate-Source Voltage	卤20	V
Maximum Drain Current (Pulsed)	430	A
Maximum Drain Current (Continuous)	120	A
Maximum Power Dissipation	300	W
Rds(on) at Vgs = 10V	4.3	m惟
Junction Temperature Range	-55 to +175	掳C
Storage Temperature Range	-65 to +150	掳C
Package	TO-247	-
