Parameter	Description	Value	Unit
Device Type	Non-Volatile Static Random Access Memory (NVS RAM)	N28F001BX-T120
Package Type	Package Type	TSSOP-8
Operating Voltage	Supply Voltage Range	1.65 to 3.6	V
Memory Size	Total Memory Capacity	128 Kbit
Data Retention	Data Retention Time	10 years
Endurance	Write/Read Cycle Endurance	1,000,000 cycles
Operating Temperature	Operating Temperature Range	-40 to +85	掳C
Storage Temperature	Storage Temperature Range	-55 to +125	掳C
Access Time	Typical Access Time	70	ns
Standby Current	Quiescent Current	1	渭A
Active Current	Active Current	20	mA

Instructions for Use:

1. Power Supply Connection:

   • Connect the supply voltage (VCC) within the specified range of 1.65V to 3.6V.
   • Ensure a stable power supply to prevent data corruption.

2. Address and Data Lines:

   • Connect address lines (A0-A12) to select the desired memory location.
   • Connect data lines (DQ0-DQ15) for reading from or writing to the selected address.

3. Control Signals:

   • Apply control signals such as Chip Select (CS), Write Enable (WE), Output Enable (OE), and Write Protect (WP) according to the timing diagrams provided in the datasheet.

4. Write Operations:

   • To write data, ensure CS is low, WE is low, and OE is high. Present the address on the address lines and the data on the data lines before toggling WE back high.

5. Read Operations:

   • For read operations, set CS low, OE low, and WE high. Present the address on the address lines and then read the data from the data lines after the specified access time.

6. Data Retention and Endurance:

   • The device retains data for up to 10 years under normal operating conditions.
   • It supports up to 1,000,000 write/read cycles without degradation.

7. Temperature Considerations:

   • Operate the device within the temperature range of -40掳C to +85掳C for reliable performance.
   • Store the device between -55掳C and +125掳C when not in use.

8. Handling Precautions:

   • Handle with care to avoid electrostatic discharge (ESD).
   • Follow anti-static protocols during installation and handling.

(For reference only)
