Parameter	Symbol	Min	Typ	Max	Unit	Conditions
Forward Voltage	VF	-	1.2	1.5	V	IF = 5 mA
Reverse Current	IR	-	-	0.1	渭A	VR = 5 V
Peak Forward Current	IF(surge)	-	-	30	mA	tp = 10 ms
Continuous Forward Current	IF	-	-	20	mA	TA = 25掳C
Reverse Breakdown Voltage	VR	-	-	5.0	V	IR = 1 渭A
Operating Temperature Range	TOP	-40	-	85	掳C	-
Storage Temperature Range	TSTG	-55	-	150	掳C	-

Instructions for Use:

1. Forward Voltage (V_F):

   • Ensure that the forward voltage across the photodiode does not exceed 1.5V when the forward current is 5mA.

2. Reverse Current (I_R):

   • The reverse current should be kept below 0.1渭A when the reverse voltage is 5V to avoid damage.

3. Peak Forward Current (I_F(surge)):

   • The peak forward current should not exceed 30mA for pulse durations of up to 10ms.

4. Continuous Forward Current (I_F):

   • The continuous forward current should not exceed 20mA at ambient temperatures of 25掳C to ensure reliable operation.

5. Reverse Breakdown Voltage (V_R):

   • The reverse breakdown voltage should not exceed 5.0V to prevent damage to the device.

6. Operating Temperature Range (T_OP):

   • The device can operate reliably within the temperature range of -40掳C to 85掳C.

7. Storage Temperature Range (T_STG):

   • Store the device in an environment with temperatures ranging from -55掳C to 150掳C to maintain its performance.

8. Handling Precautions:

   • Handle the PC812 with care to avoid static discharge and physical damage.
   • Ensure that all connections are secure and free from corrosion or oxidation.

9. Mounting:

   • Follow the recommended soldering profile to avoid thermal stress.
   • Ensure proper alignment and orientation during assembly.

10. Testing:

    • Use appropriate test equipment and methods to verify the parameters and functionality of the PC812.

(For reference only)
