PIC PIC? 24F Microcontroller IC 16-Bit 32MHz 256KB (85.5K x 24) FLASH 100-TQFP (12x12)

Parameter	Description
Device	PIC24FJ256GB210-I/PT
Package Type	TQFP-44
Operating Voltage (Vdd)	1.8V to 3.6V
Core Speed	Up to 32 MIPS (at 32 MHz)
Program Memory Type	Flash
Program Memory Size	256 KB
Data Memory (RAM)	32 KB
EEPROM Size	1 KB
ADC Channels	12-bit, up to 16 channels
Timers	5 x 16-bit timers
Communication Interfaces	I2C, SPI, UART, CAN 2.0B Active
Comparator Channels	4
PGA Channels	2
Operating Temperature Range	-40°C to +85°C
Pin Count	44
I/O Pins	35
Brown-out Reset	Yes
Watchdog Timer	Yes
Low-Voltage Programming	Yes

Instructions for Use:

1. Power Supply Requirements:

   • Ensure the operating voltage is within the specified range of 1.8V to 3.6V.
   • Use appropriate decoupling capacitors near the power supply pins to stabilize the power supply.

2. Programming:

   • The device supports In-Circuit Serial Programming (ICSP) and can be programmed using a PICkit 3 or MPLAB ICD 3.
   • Follow the MPLAB X IDE setup guide for configuring the development environment.

3. Clock Configuration:

   • Internal Fast RC Oscillator (FRC) with PLL provides up to 32 MHz operation.
   • External crystal or clock sources can also be used depending on application requirements.

4. Peripheral Setup:

   • Initialize communication interfaces like I2C, SPI, UART as per application needs using the Peripheral Library functions.
   • Configure ADC, comparators, and timers according to specific project requirements.

5. Interrupt Handling:

   • Set up interrupt priorities and enable/disable interrupts as required in your application code.

6. Debugging:

   • Utilize the built-in debugging features provided by MPLAB X IDE and hardware tools like MPLAB ICD 3 for efficient debugging.

7. Temperature Considerations:

   • Ensure the operating temperature stays within the -40°C to +85°C range to maintain reliable operation.

8. Environmental Considerations:

   • Follow proper handling procedures to avoid ESD damage, especially during soldering and assembly processes.

9. Documentation:

   • Refer to the datasheet and family reference manual for detailed information on all parameters, registers, and programming specifics.

(For reference only)
