Details
BUY ES5GC(10pcs) https://www.utsource.net/itm/p/8371900.html
| Parameter | Description |
|---|---|
| Part Number | ES5GC |
| Quantity | 10 pcs |
| Type | Schottky Diode |
| Maximum Reverse Voltage (Vr) | 40V |
| Maximum Forward Current (If) | 3A |
| Peak Forward Surge Current (Ifsm) | 60A (8.3ms single half sine wave) |
| Total Power Dissipation (Ptot) | 30W |
| Junction Operating Temperature (Tj) | -55°C to +175°C |
| Storage Temperature (Tstg) | -55°C to +150°C |
| Package Type | TO-220 |
Instructions:
- Handling: Handle the ES5GC with care to avoid damage. Use appropriate ESD protection measures.
- Mounting: Ensure proper mounting on a heatsink if operating near maximum current to maintain temperature within safe limits.
- Soldering: Solder within the recommended temperature range and time to prevent thermal damage. Typically, 260°C for no more than 10 seconds.
- Testing: Verify the diode's functionality using a multimeter or diode tester before installation.
- Storage: Store in a dry place away from direct sunlight and extreme temperatures.
- Application: Suitable for high-efficiency rectification and protection circuits due to low forward voltage drop characteristics.
